Google Summer of Code

Python Software Foundation DIPY — Diffusion Imaging in Python

I am Tomás Guija-Valiente, a computer vision and machine learning researcher at the medical imaging laboratory PROMISE–LAIMBIO. My academic background combines mathematics, computer science, and artificial intelligence. Over the past year, I have become increasingly interested in applying these skills to the medical domain, where research can have a meaningful real-world impact and open-source software plays a particularly important role.

Google Summer of Code 2026 gave me the opportunity to work at this intersection. This year, I joined DIPY through the Python Software Foundation, hoping not only to implement a new algorithm or feature, but also to learn how a mature scientific library is designed, tested, reviewed, and maintained by its community.

My project, Adding New Similarity Metrics for DIPY’s Image Registration Frameworks, focused on medical image registration: the process of estimating a spatial transformation that aligns two or more images. Registration is a fundamental component of longitudinal analysis, atlas construction, and population studies, but its performance depends heavily on how image similarity is defined and how efficiently the transformation can be optimized.

I began the summer with one main goal: adding Mutual Information to DIPY’s deformable registration framework. As the project progressed, I also worked on improving performance, testing the implementations, building better benchmarks, and refining related APIs. Overall, the project became a valuable introduction to mathematical implementation, scientific software development, and collaborative open-source work, with the guidance and support of my mentors, Serge and Atharva. Twelve pull requests and many commits later, this report brings together the main results of that experience: the new algorithms, performance improvements, fixes, and lessons learned along the way.

GSoC Blog Timeline

Throughout the project, I documented my progress through a series of weekly posts published on the DIPY blog:

Date Blog post
May 25, 2026 Starting My GSoC Journey with DIPY
June 1, 2026 First Coding Week: Benchmarking and MI Study
June 8, 2026 Second Coding Week: First MI Implementation
June 15, 2026 Third Coding Week: MI Testing and Benchmarking
June 22, 2026 Fourth Coding Week: Halfway There!
June 29, 2026 Fifth Coding Week: First MI Implementation PR
July 6, 2026 Sixth Coding Week: Profiling, Performance, and New Metric for Affine Registration
July 13, 2026 Seventh Coding Week: Cleaning Up Near the Finish Line!
July 20, 2026 Eighth Coding Week: The Final Coding Week!

Summary

Area Contribution Pull request
Deformable registration Mutual Information metric for SyN with dense, local-support derivatives #4067
Affine registration Local cross-correlation metric compatible with AffineRegistration #4078
SyN performance Threaded field composition, fixed-point inversion, and image warping #4073, #4083
MI backend Removed a redundant B-spline evaluation and unified Parzen PDF normalization #4071, #4087
CC backend Unified the duplicated forward and backward SyN CC kernels #4088
Metric correctness Fixed stale energy state after the backward CC step #4047
SynthSeg Added cleaner optional brain masks and flexible model-space dimensions #4052, #4080
Documentation Clarified 2D Parzen support and affine MI return values #4085, #4086
Evaluation Built a reproducible, SLURM-based comparison pipeline for DIPY and ANTs Benchmarking branch

1. Mutual Information for SyN registration

Pull request: #4067 — MI implementation for SyN registration

DIPY already provided Mutual Information (MI) for affine registration, while its SyN implementation supported cross-correlation, sum of squared differences, and expectation-maximization metrics. The main objective of my project was to add MI to the deformable framework, where it can support multimodal problems in which corresponding anatomy does not necessarily have similar intensity values.

Mutual information

Mutual Information asks a simple question: how much does knowing the intensity in one image tell us about the intensity in the other? For fixed- and moving-image intensities $F$ and $M$, it is written as

\[I(F;M) = \sum_{i,j} p_{FM}(i,j) \log\!\left(\frac{p_{FM}(i,j)}{p_F(i)p_M(j)}\right)\]

Here, $p_{FM}(i,j)$ describes how often intensity $i$ in the fixed image appears together with intensity $j$ in the moving image. The terms $p_F(i)$ and $p_M(j)$ describe how common those intensities are individually. If the two images are unrelated, their joint distribution is close to the product of the two individual distributions and MI is low. As the images become better aligned, their intensity relationship becomes more predictable and MI increases.

This is particularly useful for multimodal registration. A structure may appear bright in a T1-weighted MRI and dark in a B0 image, so comparing the intensities directly would be unreliable. MI does not require them to be equal; it only looks for a consistent relationship between them.

Parzen windows

In practice, these probability distributions are estimated with a joint histogram. A standard histogram uses hard assignments: each sample falls into exactly one bin. That creates abrupt jumps—a tiny change in intensity can move a sample from one bin to another—which is a problem for a gradient-based registration algorithm that needs a smooth signal telling it how to update the transformation.

DIPY follows the Mattes MI formulation and uses Parzen windows to soften those assignments. On the moving-image axis, each sample spreads its contribution across four neighboring bins using a cubic B-spline. As the intensity changes, the weights move smoothly between those bins instead of jumping abruptly. The derivative of the B-spline weights then tells the optimizer how a small intensity change would affect MI.

Implementation details

DIPY’s existing affine MI implementation produces a derivative for a small set of transformation parameters. SyN is different: it optimizes a displacement vector at every voxel. A direct extension of the affine approach would require storing derivative information for every histogram bin, voxel, and spatial dimension, which would use far too much memory.

The new implementation avoids that large intermediate representation by exploiting the local support of the Parzen kernel. For each voxel, it:

  1. identifies the fixed-image bin and the four moving-image bins affected by the sample;
  2. computes how the weights of those four bins change with moving-image intensity;
  3. combines that change with the spatial gradient of the moving image;
  4. accumulates the result directly into the voxel’s 2D or 3D displacement update.

This produces the dense vector field expected by SymmetricDiffeomorphicRegistration without constructing a histogram-by-voxel derivative tensor. The low-level work is implemented in Cython alongside DIPY’s existing Parzen-histogram code, with support for 2D and 3D float32 and float64 images.

At the Python level, the PR adds an MIMetric class that follows the same lifecycle as DIPY’s other SyN metrics: initialize the current iteration, compute forward and backward updates, and report the scalar energy. The design was informed by the local-support path in ITK’s Mattes MI metric.

The review of this work also exposed an ambiguity in the existing Parzen-histogram documentation. PR #4085 clarified that the relevant methods support 2D data as well as 3D data, making that behavior explicit for the related MI work.

Validation

I validated the implementation on the MRBrainS18 dataset, available through DataverseNL. The initial benchmark covered 100 inter-patient, cross-modality registrations using the dataset’s FLAIR, inversion-recovery, and T1-weighted images and manual segmentations. The complete preparation and evaluation protocol, together with all benchmarking code, is available in the mi-benchmarking branch.

The table reports the mean and standard deviation across the 100 registrations:

Method NCC NMI Label Dice Label Jaccard
Rigid baseline 0.362 ± 0.086 1.021 ± 0.006 0.506 ± 0.056 0.369 ± 0.051
ANTs SyN 0.561 ± 0.087 1.044 ± 0.013 0.565 ± 0.049 0.430 ± 0.046
DIPY SyN 0.549 ± 0.084 1.043 ± 0.012 0.567 ± 0.051 0.432 ± 0.048

The improvement over the rigid baseline confirms that the new DIPY MI metric produces effective multimodal registration updates.

2. Local cross-correlation for affine registration

Pull request: #4078 — CC implementation for affine registration

The second metric contribution adds local cross-correlation (CC) to DIPY’s affine API. While MI is useful when the images come from different modalities, CC is a natural choice for images from the same modality, where the same anatomy is expected to produce similar local intensity patterns.

Local cross-correlation

Instead of comparing individual pixels or voxels, local CC compares small neighborhoods. Before comparing them, it subtracts the average intensity in each neighborhood and normalizes by their local variation. This makes the metric respond to the shape of the intensity pattern rather than to simple differences in brightness or contrast.

For a neighborhood $W_x$ around voxel $x$, the squared local correlation is

\[\operatorname{CC}(x)= \frac{ \left[\sum_{y\in W_x}(F(y)-\bar F_x)(M(y)-\bar M_x)\right]^2 }{ \left[\sum_{y\in W_x}(F(y)-\bar F_x)^2\right] \left[\sum_{y\in W_x}(M(y)-\bar M_x)^2\right] }\]

In simple terms, the numerator measures whether both neighborhoods vary together, while the denominator accounts for how much each one varies on its own. The score becomes high when their local patterns match. This is the local CC formulation used in the SyN work by Avants et al. and already available in DIPY’s deformable registration backend.

Implementation details

DIPY already had optimized code for computing local CC statistics and voxel-level updates for SyN. The main challenge was adapting that machinery to affine registration, where the optimizer changes a small set of global parameters instead of a displacement vector at every voxel.

The new metric:

  1. converts the optimizer’s current parameter vector into an affine matrix;
  2. warps the moving image onto the fixed-image grid and computes the local CC factors;
  3. evaluates the moving-image gradient at the transformed fixed-grid points;
  4. uses a Cython kernel to combine the local CC factor, image gradient, and transform Jacobian directly into the gradient for each transform parameter.

At the API level, CrossCorrelationMetric follows the same optimizer-facing structure as DIPY’s existing affine MI metric, implementing setup, distance, gradient, and distance_and_gradient.

The API review also led to PR #4086, which clarified the return values of the existing MutualInformationMetric methods and made their docstrings more consistent.

Validation

In a representative 3D b0-to-b0 registration, global NCC improved at every stage:

Stage Global NCC
Identity 0.1903
Center of mass 0.4772
Translation 0.5584
Rigid 0.6656
Affine 0.6751

The consistent improvement confirms that the metric works correctly with DIPY’s affine optimization pipeline.

3. Faster SyN kernels with OpenMP

SyN spends much of its time repeatedly combining and inverting displacement fields and warping images. Since many pixels or voxels can be processed independently, these operations are good candidates for multithreading. I addressed them in two related pull requests.

3.1 Field composition and fixed-point inversion

Pull request: #4073 — Parallelize displacement-field composition

The outer composition loops now use Cython’s prange: rows are distributed across workers in 2D and slices in 3D. Each worker writes to a disjoint region of the output field.

The serial kernel also accumulated composition statistics. To avoid data races, the threaded implementation stores per-thread sample counts, sums, higher-order sums, and maxima, then merges them after the parallel region. The same num_threads configuration is propagated into fixed-point inversion, which repeatedly calls field composition.

Serial and threaded tests compare both the composed fields and the returned statistics. The following preliminary end-to-end SyN comparison used the same input images and a multiresolution iteration schedule of 20, 20, and 10:

Method Time (s) NCC
DIPY serial 301.155 0.95494
DIPY threaded 243.676 0.95494

Threading produced a 1.24× speed-up over serial DIPY while preserving the same NCC. The complete implementation used for this experiment is available in the speed-syn branch.

3.2 Image warping

Pull request: #4083 — Multithreading 2D and 3D image warping

The follow-up PR parallelizes warp_2d, warp_2d_nn, warp_3d, and warp_3d_nn, covering linear and nearest-neighbor interpolation. Dedicated row and slice helpers give each worker its own interpolation buffer. DiffeomorphicMap and SymmetricDiffeomorphicRegistration forward the optional thread count while preserving compatibility with existing calls. Tests compare one-thread and multi-thread results across both dimensions, both interpolation modes, and forward and inverse map operations. A small 3D SyN timing experiment produced the following results:

Revision and mode Time (s) NCC
Four threads 76.864 0.95741
DIPY master 110.465 0.95741

Using four threads reduced runtime while preserving the final NCC.

4. Registration fixes and backend cleanups

4.1 Removing a redundant Parzen evaluation

Pull request: #4071 — Avoid redundant Parzen spline-bin evaluation

While developing MI for SyN, I noticed that the histogram loop checked five moving-bin offsets: [-2, -1, 0, 1, 2]. The -2 offset is always at least two bins away from the continuous bin coordinate, where the cubic B-spline weight is zero. In practice, only [-1, 0, 1, 2] can contribute.

The change removes that evaluation from PDF and gradient computations and replaces hard-coded radius values with the existing padding variable.

4.2 Consistent Parzen PDF normalization

Pull request: #4087 — Simplify Parzen PDF normalization

Dense 2D, dense 3D, and sparse Parzen-histogram paths previously normalized their PDFs in different ways. This merged PR makes them consistently use valid_points and removes the redundant total_sum accumulation. Under the standard AffineRegistration workflow, where image intensities are normalized to $[0,1]$, this preserves the expected numerical behavior while keeping the PDFs and their gradients consistent. Excluding samples mapped outside the moving-image domain remains a separate, larger improvement.

4.3 Correct energy state after backward CC updates

Pull request: #4047 — Update CCMetric energy after backward step

CCMetric.compute_backward() computed the backward energy but did not assign it to self.energy. Direct API users could therefore receive a stale or unset value from get_energy().

The fix makes the backward path consistent with the forward path and with other metrics. Tests for CCMetric and SSDMetric now verify energy reporting after independent forward and backward computations. The issue was silent in the standard SyN workflow and was not expected to alter its registration result, but the fix makes the metric contract reliable for direct and custom use.

4.4 Unifying the forward and backward CC steps

Pull request: #4088 — Unify forward and backward CC steps

While working on affine CC, I found that the existing SyN forward and backward kernels duplicated almost all of their allocation, voxel loops, validity checks, energy calculation, and output logic. This PR consolidates them into shared 2D and 3D functions, with an explicit argument selecting the update direction, without changing the numerical behavior.

5. Robust SynthSeg integration

SynthSeg is designed to segment brain scans across contrasts and resolutions without retraining. Two contributions improve how DIPY exposes its masks and prepares model inputs.

5.1 Consistent and configurable brain masks

Pull request: #4052 — Remove holes and islands from SynthSeg masks

A mask obtained directly from predicted labels can contain small disconnected components or internal holes. This PR proposes making brain-mask generation a consistent part of SynthSeg.predict(), with a finalize_mask option that uses DIPY’s existing remove_holes_and_islands function to clean those artifacts. Users can disable this step when they need the direct foreground mask given by labels > 0.

The PR also standardizes the returned labels, label dictionary, and mask, and forwards the same option through BrainMaskFlow. It explicitly distinguishes probability maps in SynthSeg’s model space from masks recovered to the original image space, and adds tests for raw and finalized masks, probability outputs, shapes, and dtypes.

5.2 Flexible model-space dimensions

Pull request: #4080 — Flexible input for SynthSeg

DIPY previously forced every resampled input into a fixed $192\times192\times192$ model space, which could crop images with a larger field of view. The proposed preprocessing instead:

  1. resamples the image to 1 mm isotropic resolution;
  2. retains the complete resampled field of view;
  3. pads each spatial dimension to the smallest multiple of 32;
  4. recovers labels and masks in the original input space.

For a resampled dimension of length $s$, the compatible size is

\[s_{\mathrm{pad}}=32\left\lceil\frac{s}{32}\right\rceil.\]

This matches the reference SynthSeg implementation, where cropping is optional and any requested crop size must be divisible by 32. Visual checks on OASIS-2 samples showed that the flexible path preserved anatomy that the fixed-size preprocessing could exclude.

6. Reproducible evaluation against ANTs

Alongside the DIPY changes, I developed a registration benchmark to compare DIPY with ANTs under a shared protocol. The pipeline provides:

  • common rigid prealignment;
  • DIPY and ANTs SyN backends;
  • monomodal and multimodal metrics;
  • nearest-neighbor warping for anatomical labels;
  • NCC and normalized MI for image similarity;
  • Dice and Jaccard overlap for labels;
  • one result file per fixed–moving pair;
  • SLURM job arrays;
  • aggregation into summary JSON files.

The benchmark is designed to compare the SyN optimization stage itself, rather than complete pipelines with different preprocessing or initialization. Both frameworks receive the same prepared images and rigid prealignment, and their settings are matched as closely as their interfaces allow. The accompanying documentation includes an in-depth comparison of the DIPY and ANTs implementations, their parameter conventions, and the decisions required to make the experiments comparable.

The original code and framework studies are available in the registration-benchmark branch, which is now deprecated. The newer mi-benchmarking branch extends the pipeline with Mutual Information as a SyN metric, although it currently needs to be rebased before further experiments are run.

Conclusion

Taken together, these contributions strengthened several layers of DIPY’s registration ecosystem, from similarity metrics and numerical kernels to preprocessing and evaluation.

The principal outcomes are:

  • a dense local-support Mutual Information formulation for SyN;
  • a local cross-correlation metric for affine registration;
  • multithreaded composition, inversion, and warping kernels;
  • focused improvements to Parzen normalization, CC backend reuse, and registration documentation;
  • more robust SynthSeg mask and input-size handling; and
  • a reproducible framework for comparing DIPY and ANTs.

Beyond the pull requests, commits, and lines of code, the most valuable outcome of this project has been the experience itself. It is remarkable how much can be learned in just over two months. This was my first real introduction to open-source development, and it showed me that implementing an idea is only the beginning.

Writing code has never been more accessible, especially with the tools available today. Contributing to a mature open-source project is a completely different challenge. The real work lies in producing code that is readable, well documented, robust, scalable, tested, and consistent with a well-established codebase used by thousands of people. Understanding that difference—and experiencing the care, discussion, and review required to reach that standard—has been one of the most important lessons of this project.

For that reason, the end of GSoC does not feel like an ending. I see it as the beginning of what I hope will be a long and rewarding journey contributing to free and accessible open-source software. I plan to continue supporting the contributions that remain under review, working with DIPY, and participating more broadly in the open-source community to help build useful tools that anyone can access.

I am especially grateful to my mentors, Serge Koudoro, Atharva Shah and Jong Sung Park, for their guidance, patience, thoughtful reviews, and trust throughout the project. I also want to thank the wider DIPY community for welcoming me and making this first experience in open source such a meaningful one.
